Slotted Channel
Discreet slot drain for public & commercial areas.
Your benefits with SLOTTED CHANNEL
With a slotted inlet of 10mm, the paverslot channel offers neat and discreet surface drainage for design-sensitive applications. The system harmoniously blends into the surface appearance with only unobtrusive narrow lines visable. The channel body is manufactured from 100% recycled composite and fitted with a 105 mm asymmetrical slot cover available in galvanised or stainless steel. Various channel depths are available, including shallower trench drains where installation depth is restricted.
-
Integrated tongue and groove connection of channels and slot components enables ease of installation
-
Structural reinforcements under the cover and the material thickness (4 mm) provides a perfect balance between weight and stability
-
Withstand loads up to class D 400 according to EN 1433
-
Asymmetrical duo slot available with a width of 2 x 6 mm
-
Connection to outlet pipes is possible from trash box and channels (from the side or bottom)
-
Access cover normally fitted on top of trash box but can also be fitted directly on channel base
-
Individual solutions: slotted components with modified neck height, crossbars in the slot and corner connections can be manufactured
-
High-quality and sustainable materials offer corrosion protection and recyclability of the individual components
The HAURATON Product Finder
You are in the category „“. There are no matching products to your selection here. You may find suitable products for your specific search in another category.
There are no matching products for your selection. Please select other filters in the product finder.
You are in the category „“. There are no matching products to your selection here. You may find suitable products for your specific search in another category.
There are no matching products for your selection. Please select other filters in the product finder.
You are in the category „“. There are no matching products to your selection here. You may find suitable products for your specific search in another category.
There are no matching products for your selection. Please select other filters in the product finder.
Asymmetrical covers made of galvanised or stainless steel. With integrated push connector for precise slot guidance on the surface.
End cap with outlet
Channels made of PP or fibre reinforced concrete in nominal sizes 100 and 150, with groove and tongue connection for exact installation
Trash box with pipe connection possibility, with fitting access cover
System components
SLOTTED CHANNEL
Sustainable material
The raw material for RECYFIX comes from recycled goods used in everyday life such as packaging, freezer bags and disposable plastic bottles. By utilising these items in the manufacturing process of RECYFIX channels, it protects the environment by reducing mountains of waste.
Environmental credentials
RECYFIX channels carry the Blue Angel environmental label, a recognised award in Germany for resource-saving use of materials. The trench drains are PVC-free and fully recyclable following lifetime use.
Videos
Case Studies with SLOTTED CHANNEL
The SLOTTED CHANNEL has been utilised in many design-conscious applications such as public spaces, market squares, façades and commercial areas.
